MERCURIO – LEAVES

MERCURIO - LEAVES - INCLUSIVE STRUCTURE, 5 MULTILEVEL TOWERS, SLIDES AND ACCESSIBLE LIFTS / +AF705PAH_L_ALU

• N. 1 NG Tic-Tac-Toe Panel Leaves - Two colored polyethylene panel with serigraphy XOX symbols, 9 half-moon rolling panels, Inox steel bolts.
• N. 1 NG Mirror Panel Leaves - .
• NR 1 NG Swing kit with seat - Made with painted steel girder and two easel supporting griders in lamellar wood. Rubber anti-shock seat with metal reinforcement inside. Chains made by hot galvanized steel rod; chain mesh avoiding fingers entrapment. Joints made by hot galavnized steel with swinging central joint
• N. 1 NG Helicopter Activity Panel Leaves - Made of colored polyethylene, sandwich type, with flow lanes, rotating disk and central knob
• NR 1 NG Hexagonal tower less roof - made of 6 aluminum beams, 1 hexagoal platform and mounted at 40 cm height
• N. 1 NG Large Leaf Accessory - Leaves panel
• N. 2 NG Small Leaf Accessory - Leaves panel
• N. 2 NG Green Simple Panel - Panel made of HDPE polyethilene, bi-color 86cm in width with drawing on the outer layer. all the fixing elements in Stainless steel
• NR 1 NG Angular baby gym - Vertical net with frame made of lamellar wood beams fixed through disappearing and passing nuts and bolts. Bars realized with stainless steel tubular pegs, mounted into two lateral wooden supports Climbing cord.
• N. 1 NG Basic Straight Bridge Leaves - Walkway made of impregnated wood, with plyethylene parapets
• NR 1 NG Tibetan bridge - The net is made of steel strands rope, 18 mm diameter, covered with a colored nylon braid, highly resistant. The knots are covered with shell-shape protections.
• NR 1 NG Fantasy Railing - Fantasy railing in painted steel
• NR 1 NG Square tower without roof h90 cm - h90 cm tower without roof made of 4 EN EV6060 anodized alumium post with custom mold 9x9cm with rounded edges, minimum thickness 2,7mm. Central platform made of HDPE polyethilene with anti slip coating and painted and anodized steel brackets. All the fixing elements made of stainless steel
• N. 1 NG Tower h140 with Roof Leaves - Composed by 4 posts having a 9 x 9 cm section by aluminium, 1 square platform placed at a height of 140 cm. Coloured polyethylene gable roof.
• NR 1 NG Inclusive staircase h40 cm - Inclusive stair h40 made of carply and aluminum
• N. 1 NG Poly-Inox Slide h140 Leaves - slide with lateral sides made of polyethylene and stainless steel slide certified according to the existing rules; starting platform height 140 cm; provided with a transversal bar.
