AF101B.ALT-01 style ALU
HOOK BABY CON ALTALENA ALLUMINIO
double tower with slides and swing


DESCRIPTION
HOOK BABY CON ALTALENA ALLUMINIO - double tower with slides and swing / AF101B.ALT-01 style ALU / Made of EN EV6060 anodized alumium 9x9cm custom mold with rounded edges, minimum thickness 2,7mm
- NR 1 Pannelli laterali di protezione oblo' - Realizzati in polietilene colorato e oblo' in policarbonato trasparente, completi di staffe in acciaio inox per il fissaggio alla torretta.
- NR 1 Square tower h 90 cm with tubular type roof alluminium - Made of 4 aluminum beams, 1 squared footboard h90 cm with tubolar roof
- NR 1 Shop panels - Vertical panel made of polyethylene and wood shelf.
- NR 1 Playground table attachment - Playground table made of HDPE Polyethilene with an aluminium beam support and a flower shaped HDPE seat
- NR 1 Straight slide Inox - slide with lateral sides made of polyethylene and stainless steel slide certified according to the existing rules; starting platform height 90 cm; provided with a transversal bar.
- NR 1 Square tower h 60 cm without roof - Composed of 4 posts having a 9 x 9 cm section by aluminium, 1 square platform placed at a height of 60 cm
- NR 1 Swing kit with seat - Made with painted steel girder and two easel supporting griders in lamellar wood. Rubber anti-shock seat with metal reinforcement inside. Chains made by hot galvanized steel rod; chain mesh avoiding fingers entrapment. Joints made by hot galavnized steel with swinging central joint
- NR 1 Straight slide h 90 cm - slide with lateral sides made of polyethylene and stainless steel slide certified according to the existing rules; starting platform height 90 cm; provided with a transversal bar.
- NR 1 Fantasy Railing - Fantasy railing in painted steel
- NR 1 Step Flower - Polyethilene flower supported by a galvanized steel bean
- NR 2 Fantasy holding bar - Fantasy steel holding bar L.860
TECHNICAL CHARACTERISTICS
Impact area (mq): | 11 |
Size (cm): | 600 x 320 x 280 |
Safety area (cm): | 770 x 760 |
Falling height (cm): | 90 |
MATERIALS OF CONSTRUCTION

PLAYING CHARACTERISTICS
